AP-810 1/2 Ton Manual Adjustable Head Precision Lever Presses
Building high-quality US-made manual presses, such as the AP-810 Adjustable Head Precision Lever Press, has been our mission for over 50 years. Our presses and components are made in our Janesville, Wisconsin manufacturing facility. We manufacture several versions of this 1/2 ton press, including adjustable head precision lever, adjustable handle precision lever, full stroke precision lever, adjustable handle full stroke precision lever and adjustable precision lever.
Review our dimensions and pricing chart to find the right manual press for your application, or use our Press Customization Form for a fully custom solution.
AP-810 1/2 Ton Adjustable Head Precision Lever Press
The AP-810 manual precision press offers flexible customization options, including adjustable heights and a rotating head design. Choose from the standard base model or several specialized configurations designed for unique production needs.
AP-810 Base Model
This manual rack and pinion press features a 3/4” square ground ram and adjustable gib for continual accuracy. Designed with more working clearance than the popular ILP-500, the AP-810 provides added flexibility for larger applications. This hand arbor press is ideal for precision assembly, punching, shearing and forming light-gauge metal or plastic components.
The AP-810 features a 9-and-7/8" long ram with 7-and-7/8" of clearance under the ram with 4-and-31/32” of depth. The 11-and-3/4" column can be custom ordered to any length upon request.
Hand Press Model Configurations For Additional Functionalities
AP-810-AH 1/2 Ton Adjustable Handle Precision Lever Press
This variation of the AP-810 base model incorporates an adjustable handle for easy left-handed operation. The handle can adjust at 30-degree increments for greater accuracy and lower production time.
The handle adjusts in 30-degree increments to improve operator positioning, accuracy and production efficiency.
AP-810-FS 1/2 Ton Full Stroke Precision Lever Press
With full stroke modification, the entire stroke must be completed before it is returned. The down-stop and upstroke limiter requires engagement with the drive bar before the stroke is lifted.
This full-stroke hand die press is ideal for applications requiring complete stroke consistency.
AP-810-AH-FS 1/2 Ton Adjustable Handle Full Stroke Precision Lever Press
Combining adjustable handle positioning with full-stroke control, this model delivers added versatility and precision. With the AH-FS model, you get all the functionality from the base model plus the AH and FS models.
AP-810-AH-T-A-2(SL's) 1/2 Ton Adjustable Precision Lever Press
This configuration includes a larger T-slot base to provide additional workspace and tooling flexibility. It has an adjustable handle attachment, two stroke limiters, attachment buttons for die sets and a lower bushing for easy connection with die sets.
AP-810 Lever Press Informational Product Video
Shop all 100% American-made arbor hand presses for sale from Janesville Tool & Manufacturing.
AP-810 Parts & Attachments
Keep your AP-810 manual press operating at peak performance with high-quality replacement parts and press attachments from Janesville Tool & Manufacturing.
Replacement Parts for AP-810 Manual Presses
We offer replacement parts for AP-810 manual hand presses, including rams, handles, gibs, springs, pins and additional press components manufactured for long-lasting reliability. Whether you’re performing routine maintenance or restoring an older machine, our American-made parts are built for dependable performance and consistent accuracy.
Available attachments for your manual rack and pinion press include adjustable handles, adjustable down stops, stroke limiters, die set arrangements and more.
Our team can modify your AP-810 hand die press with custom column lengths, tooling integrations and additional functionality tailored to your manufacturing or assembly requirements.
AP-810 1/2 Ton Adjustable Head Precision Lever Press
The AP-810 manual precision press offers flexible customization options, including adjustable heights and a rotating head design. Choose from the standard base model or several specialized configurations designed for unique production needs.
AP-810 Base Model
This manual rack and pinion press features a 3/4” square ground ram and adjustable gib for continual accuracy. Designed with more working clearance than the popular ILP-500, the AP-810 provides added flexibility for larger applications. This hand arbor press is ideal for precision assembly, punching, shearing and forming light-gauge metal or plastic components.
The AP-810 features a 9-and-7/8" long ram with 7-and-7/8" of clearance under the ram with 4-and-31/32” of depth. The 11-and-3/4" column can be custom ordered to any length upon request.
Hand Press Model Configurations For Additional Functionalities
AP-810-AH 1/2 Ton Adjustable Handle Precision Lever Press
This variation of the AP-810 base model incorporates an adjustable handle for easy left-handed operation. The handle can adjust at 30-degree increments for greater accuracy and lower production time.
The handle adjusts in 30-degree increments to improve operator positioning, accuracy and production efficiency.
AP-810-FS 1/2 Ton Full Stroke Precision Lever Press
With full stroke modification, the entire stroke must be completed before it is returned. The down-stop and upstroke limiter requires engagement with the drive bar before the stroke is lifted.
This full-stroke hand die press is ideal for applications requiring complete stroke consistency.
AP-810-AH-FS 1/2 Ton Adjustable Handle Full Stroke Precision Lever Press
Combining adjustable handle positioning with full-stroke control, this model delivers added versatility and precision. With the AH-FS model, you get all the functionality from the base model plus the AH and FS models.
AP-810-AH-T-A-2(SL's) 1/2 Ton Adjustable Precision Lever Press
This configuration includes a larger T-slot base to provide additional workspace and tooling flexibility. It has an adjustable handle attachment, two stroke limiters, attachment buttons for die sets and a lower bushing for easy connection with die sets.
AP-810 Lever Press Informational Product Video
Shop all 100% American-made arbor hand presses for sale from Janesville Tool & Manufacturing.
AP-810 Parts & Attachments
Keep your AP-810 manual press operating at peak performance with high-quality replacement parts and press attachments from Janesville Tool & Manufacturing.
Replacement Parts for AP-810 Manual Presses
We offer replacement parts for AP-810 manual hand presses, including rams, handles, gibs, springs, pins and additional press components manufactured for long-lasting reliability. Whether you’re performing routine maintenance or restoring an older machine, our American-made parts are built for dependable performance and consistent accuracy.
Available attachments for your manual rack and pinion press include adjustable handles, adjustable down stops, stroke limiters, die set arrangements and more.
Our team can modify your AP-810 hand die press with custom column lengths, tooling integrations and additional functionality tailored to your manufacturing or assembly requirements.
